Infrared Automatic Bridge Stone Cutting Machine HSQ-700 is mainly used for granite, marble cutting, with many advantages such as rational construction, steady movement, high accuracy, convenient installation and maintenance. Compared with similar products, the advantages are obvious. It is a very important and common equipment in stone processing equipment.
TECHNICAL DATA FOR HLSQ-700 | ||||||
Configuration | Diameter of blade | mm | Φ400 - 700 | |||
Power of main motor | kw | 18.5 | ||||
Working platform dimensions | cm | 320 x 200 | ||||
Main Performance Parameters | Max. processing dimensions | mm | 3200 x 3200 x 220 | |||
Working platform tilting degree | n° | 0-85 | ||||
Working platform rotating degree | n° | 90-360 | ||||
Water consumption | m 3/h | 4 | ||||
Measurement | Gross weight | kg | 6100 | |||
Dimension (L x W x H) | cm | 600 x 500 x 280 | ||||
Main Features
1) Controlled by PLC, operated expediently, accurately and stably.
2) Cutting head can tilt 45° for mitre cuts (Optional function).
3) Working table can tilt at 85 degrees for easy loading slabs and rotates 360 degree for ideal cutting. A full 360° rotating table enables precision cutting of material edges.
4) Laser device is adopted for slab positioning accurately.
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
